Description
Features:
- For use with 13/16″ wide channel
- Holes for 3/8″ fasteners
- EG coated for corrosion protection
Specifications
General Specifications
Standard Dimensions:
- Hole Diameter:9/32″ (7.1mm)
- Hole Spacing (From End):13/32″ (10.3mm)
- Hole Spacing (On-Center): 11/16″ (27.0mm)
- Width:13/16″ (20.6mm)
- Thickness:1/8″ (3.2mm)
Materials & Finishes
Materials & Finishes:
- Electrogalvanized (EG): Conforms to ASTM B633, Type III SC1 or SC3
Downloads
P6454 Cut Sheet
P6454 Fitting BIM Model
