Description
Features:
- Vertical Design Load: 400 to 1,200 lbs per clamp
- 3/4″ to 1″ max flange thickness
- This series is available in Electrogalvanized (EG)
Design Loads
| Design Loads- P2898 | ||
|---|---|---|
| Part Number | Rod Size in |
Design Load lbs (kN) |
| P2898-37 | 3/8″ | 400 (1.78) |
| P2898-50 | 1/2″ | 500 (2.22) |
| P2898-62 | 5/8″ | 600 (2.67) |
| P2898-75 | 3/4″ | 800 (3.56) |
| P2898-87 | 7/8″ | 1,200 (5.34) |
- Maximum temperature of 450F (232C).
- At least one full thread must be exposed.
Materials & Finishes
Materials & Finishes:
- Electrogalvanized (EG): Conforms to ASTM B633, Type III SC1 or SC3
Downloads
P2898 Cut Sheet
